Modal Àir.: LTN154X9-L01
LTN154x9-L01 Tha am modal seo uidheamaichte le solas cùl-taic CCFL, gun draibhear air a 'stiùireadh air bhog, gun suathadh. Is iad na feartan àbhaisteach aige: uachdar sgàthan. Is e an teòthachd obrachaidh aige 0 ~ 50 ° C, agus tha an teòthachd stòraidh aige -20 ~ 60 ° C.
Is e rùn taisbeanaidh Ltn154xx9-L01 × 800 (WXGA), an co-mheas taobh 16:10 (àirde), agus tha na piogsail air an rèiteachadh ann an stiallan dìreach RGB. Is e meud na sgìre taisbeanaidh aige 331.2 × 207 (Leud × 2535.0 × 226 (àirde) × 7 (tighead) mm. Air a làimhseachadh gus uachdar sgàthan (Haze 0%), còmhdach cruaidh (3mh).
C: Dè an t-seirbheis ro-reic agus às deidh às deidhinn a th 'agad?
A: a thaobh seirbheis ro-reic, tha sgioba reic proifeasanta agus sgioba teignigeach againn, a tha deònach do cheistean a fhreagairt taobh a-staigh 24 uair a-staigh 24 uair a thìde.
C: Ciamar a lorgas mi an toradh ceart?
F: Cuir thugainn na riatanasan agad, bidh sinn a 'moladh ar toraidhean àbhaisteach, mura h-eil e iomchaidh, nì sinn an atharrachadh riatanach & an gnàthachadh riatanach.
| brand | SAMSUNG | Model name | LTN154X9-L01 |
| size | 15.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1280(RGB)×800 | Pixel configuration | RGB vertical bar |
| Display Area | 331.2×207(H×V)mm | Surface treatment | Glare (Haze 0%), Hard coating (3H) |
| Visual size | 335.0×210.7(H×V)mm | Contrast Ratio | 600:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 344×226×7(H×V×D)mm |
| Viewing Angle | 65/65/50/50 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C |
| Signal interface | LVDS (1 ch, 6-bit) ,erminal,30pins |
|
|
| supply voltage | 12.0V (Typ.) |
|
|
