Min. Òrdugh:1 Piece/Pieces
Modal Àir.: TDA150-005V01
TDA150-00-00-00-00-00-00-00-0021 A bharrachd-si tt-lcd 15-òirleach Tha beatha le cùl-taic le dath geal, a 'toirt a-steach draibhear stiùir, uachdar matte. Is e an teòthachd obrachaidh aca -20 ~ 70 ° C, agus an teòthachd stòraidh aige -30 ~ 80 ° C .0 ° C. Is e an rùn taisbeanaidh 1600 (RGB) × 1200 (UXGA), agus tha na piogsail air an rèiteachadh ann an stiallan RGB. Is e meud na sgìre taisbeanaidh aige 304.8 × 228.6 (W × h) mm, agus tha an taobh a-muigh 317.4 (h) mm.
Tha e na stòr solais cruinn-loidhne le beatha 30k uairean a-thìde, a 'toirt a-steach draibhearan fo stiùir. TDA150-00-00-00-00-00-00-00-00- Addopts LVDS (2-b, 2-bit), a tha ceangailte le cinn-uidhe, agus tha an bholtachd dràibhidh 3.3v (tearmhach.).
C: Cò sinn?
A: Rh-Runch bhon Shenzhen, Sìona, Tha sinn nar neach-dèanamh proifeasanta de 10.1 gu 120 òirleach Prìomh mhodalan Tft LCD, tha còrr air 100 neach-obrach, a 'toirt a-steach 20 innleadair eòlach. Tha a 'chompanaidh air a dhol seachad air ISO9001 / ISO14001 / CCC / CCC / CCC / CCC / FCC / FC agus teisteanasan eile tha mòran chompanaidhean cruinne.our air a dhol gu mòr Asia, tuath Tha Ameireagaidh, Afraga, Ear Meadhain, an Roinn Eòrpa, Meadhan na Roinn Eòrpa agus Oceania.
C: A bheil thu a 'dèanamh (factaraidh)?
A: Tha, tha sinn. Ùine OEM / ODM ri fhaighinn an seo. Gus do bheachdan a cho-roinn leinn. Tha e na thoileachas dhuinn am fuasgladh as fheàrr a thoirt dhut.
C: Ciamar as urrainn dhuinn gealltainn càileachd?
A: Sgrùdadh Deireannach an-còmhnaidh mus tèid an lìbhrigeadh.
| brand | BOE | Model name | TDA150-005V01 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Min.)(CR≥10) | Outline dimension | 317.4 × 242 mm (H×V) |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal, 40 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
Tha an aon mheud agus modail mar a leanas:
| brand | BOE | Model name | RT150X0M-N10 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8×228.6mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 1100cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) | Outline dimension | 326.5×253.5(H×V) |
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | DV150X0M-N16 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768, XGA, 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096(H×V) mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89(Min.)(CR≥10) | Outline dimension | 326.5×253.5×9.7mm(H×V×D) |
| Signal interface | 20 pins LVDS (1 ch, 8-bit) , erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
| brand | BOE | Model name | RV150U0M-N00 |
| size | 15 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1600(RGB)×1200 [UXGA] 133PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.8 × 228.6 mm (H×V) | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | 307.2 × 231 mm (H×V) | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 317.4×242 mm(H×V×D) |
| Viewing Angle | 85/85/85/85(Min.)(CR≥10) |
|
|
| Signal interface | LVDS (2 ch, 8-bit),40 pins, erminal |
|
|
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
|
|
