Min. Òrdugh:1 Piece/Pieces
Tha UV215FHM-N10 na mhodal criostail leaghaidh 21.5-òirleach le teicneòlas A-Si le Teicneòlas LCD, is e an rùn taisbeanaidh 19: 9 (Leud), agus am Pixel Tha adopts RGB air a rèiteachadh ann an stiallan dìreach. Is e meud na sgìre taisbeanaidh aige 476.64 × 268.11 (W 4 H) Tha 479.8 × 291.2 (h) × 11.2 (d) mm.
Air a làimhseachadh mar matte (Haze 25%), còmhdach cruaidh (3h), is e an teòthachd obrach aige -20 c, agus an teòthachd stòraidh aige -30 ~ 85 ° C. Airson soidhnichean didseatach. Stòr solais t-seòrsa iomall, is e beatha seirbheis an stòr solais 30K Uairean, a 'cleachdadh LVDS (2-bit) le bhith a' cleachdadh ceangal crìochnachaidh, tha an bholtadh dràibhidh 5.0v (tearc.) .
C: A bheil meud no sònrachadh eile ann?
F: Ma tha feum agad air diofar mheudan no sònrachaidhean, bheir sinn an sgeama as freagarraiche a rèir do riatanasan.
C: Dè an t-seirbheis ro-reic agus às deidh às deidhinn a th 'agad?
A: a thaobh seirbheis ro-reic, tha sgioba reic proifeasanta agus sgioba teignigeach againn, a tha deònach do cheistean a fhreagairt taobh a-staigh 24 uair a-staigh 24 uair a thìde.
C: Ciamar as urrainn dhuinn dàimh gnìomhachais fad-ùine fad-ùine a chumail suas?
A: Bidh sinn a 'cumail suas deagh phrìsean math agus farpaiseach gus dèanamh cinnteach gu bheil luchd-ceannach a' faighinn buannachd; Tha sinn a 'toirt urram don luchd-ceannach agus bidh sinn gan làimhseachadh mar charaidean. Ge bith càite an tig iad bhuaithe, bidh sinn a 'dèanamh gnìomhachas còmhla riutha agus a' dèanamh charaidean.
| brand | BOE | Model name | UV215FHM-N10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C |
Paramadairean den aon mheud meud
| brand | BOE | Model name | DV215FHM-R01 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -20 to 85 °C Operation Temperature: -20 to 85 °C |
Tags teth: 21.5 "Bee UV215FHM-N10 Modal Pannal A-muigh, Prìs LCD a-muigh, 2000niss scrion scret-scrion LCD , Pannal airson Tbh a-muigh
Boe TDA150-005mi01 15 "CARAID SCALL SCALL
Boe ev101wxmm-n81 High Scretness LCD
