Min. Òrdugh:1 Piece/Pieces
Modal Àir.: BA104S01-100
Is e Baba104sg01-100 na Bhathar a 'mhodal modal LCD LCD air a chuir air bhog le Buidheann Teicneòlas Bee, Ltd. (Boe) a 'cleachdadh teicneòlas A-SI TFD-LCD. Tha e uidheamaichte le cùl-raon air a shàrachadh, gun draibhear cùl-taic no gun suathadh. Tha BA104S01-100 a 'taisbeanadh rùn de 800 (RGB) × 600 (SVGA), co-chruinneachadh taobh), a rèir an t-Sònrachadh Cleas RGB, a rèir an t-Sònrachadh CEIST .1 Air a leigeil a-mach le Boe air 12 Dùbhlachd, 2014. Tha meud na sgìre taisbeanaidh aige 211.2 (Leud × 172.9 (Snothaichean × × 5.9 (tighead) mm, làimhseachadh uachdar soilleir, tha cuideam lom de thoraidhean 288G (Tylet.). Backlight Tha an toradh seo a 'cleachdadh Stòr solais Taisgidh 6S6P (mullach), is e beatha an stòr solais 50K uairean, gun draibhear cùl-taic. Bidh Baba104S01-100 a 'gabhail LVDS LVDS (1 C, 6/8-bit, a' gabhail ri ceangal crìochnachaidh, valt screen dràibhidh 3.3v (tearc.). Is e 60hz a h-ìre àbhaisteach a tha a fV. Bidh e ag obair aig -20 ° C ri 70 ° C agus stòran aig -30 ° C gu 80 ° C. Thathas a 'moladh a' mhodail seo airson a bhith a 'dèanamh dealbh-bheachd gnìomhachais is meidigeach air sgàth an raon cùl-taic a stiùireadh gheal, còrr air FLIFIE, 6/8 pìosan de sgèile Làna Lian, agus feartan eile.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Tha na leanas nan aon mhodalan agus paramadairean
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Tags Hot: BOE BA104S01-100 Brùnach 500 Pannal TFD-LCD, SIMPTATIONS, SCITLE INTCHE, Screit a-muigh, 19mh LCD, Sgrion LCD airson a-muigh , Pannal LCD, Modal LCD, Taisbeanadh àrd soilleireachd.
