Min. Òrdugh:1 Piece/Pieces
Modal Àir.: RS320NET-ND10
Size: 32"
Brightness: 1000 nits
Resolution: 1920*1080
Operating Temperature: 0~50°C
Tha Monicum Monioncadh 32-òirleach a 'toirt seachad àite taisbeanaidh nas motha airson Taisbeanadh eadar-ghnìomhach de thagraidhean eile.
Gheibhear na scrionaichean suathadh sin gu cumanta ann an àrainneachdan malairteach, taighean-bìdh, agus oifisean, a bharrachd air duilleagan eadar-ghnìomhach, agus tagraidhean eile a dh 'fheumas taisbeanaidhean mòra a tha ag iarraidh taisbeanaidhean mòra.
Leis an teicneòlas as fhreagarrachd, tha na scrionaichean sin a 'toirt grunn eòlasan eadar-ghnìomhach airson seòladh, taghaidhean a thaghadh, agus ag eadar-obrachadh le fiosrachadh didseatach.
Feart toraidh:
Pannal screen 1.Tft LCD LCD
2.1920 * Ath-rùn 1080 (3840 * 2160 roghainneil)
3.Outdoor air a chleachdadh, soilleireachd bho 500nits gu 3500 nits roghainneil
Pannal Touch 4.Capaaccessitive, air a chòmhdach le glainne uidheamaichte 2mm airson dearbhadh do mhealladh
5.vga HDMI DVI ASTFFEFE ISB
Prìomh bhòrd-coileanaidh 6.high, 7/24 A 'GABHAIL A-STEACH
7.Support 12-24v Bloltage farsaing
JOZEL THOPE XUPLE XMTRYM 3MM, air leth freagarrach airson àite freumhaichte
Embedded Lcd screen with touch |
|
Model |
RS320NET-ND10 |
Waterproof | No. (Waterproof IP55/ip65 optional ) |
LCD Type | 32inch TFT-LCD |
Video Input | VGA and DVI and HMI ect (customized) |
OSD controls | Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset |
Power Supply |
Type: External brick ; Input (line) voltage: 100-240 VAC, 50-60 H Output voltage/current: 12 volts |
Mount Interface |
1) VESA 75mm and 100mm 2) Mount bracket, horizontal or vertical |
LCD Specification |
|
Resolution | 1920*1080p FHD |
Viewing angle (v/h) | 89/89/89/89 |
Contrast | 1300:1 |
Luminance(cd/m2) | 1000 (500-3500nits optional) |
Response Time | 6s |
Support Color | 16.7M colors |
Backlight MTBF(hr) | 50000 |
Touchscreen Specification |
PCAP |
Type | 10 point capacitive touch |
Light Transmission | 92% |
Touch Life Cycle | 50 millions |
Touch Response time | 16ms |
Touch System Interface | USB interface |
Environment |
|
Temperature | Operating Temp. : 0~50°C Storage Temp. : -20~60°C |
Humidity |
Operating RH. : 20%~80% Storage RH. : 10%~90% |
